Terminal Type | N/A |
Mounting Hole Quantity | 6 |
Distance From Clutch To Mounting Flange | 1.76 |
Clutch Maximum Diameter | 7.4 |
Mounting Type | Flange |
Rotation | REV |
Color | Raw Aluminum in Color |
Use Type | Severe |
Bolt Hole Quantity | 6 |
Material | Aluminum |
California Proposition 65 | WARNING: This product contains a chemical known to the State of California to cause cancer. |
Fan Mount Dia. IN | 5 |
Clutch Type | D - Severe Duty & Truck Fan Drive |
Mount Type | Flange |
O.E. Replacement? | Yes |
New or Reman | New |
Meets / Exceeds OEM? | Yes |
SDS Required | No (135233618) |
Performance Rated? | Yes |
Bolt Quantity | 6 |
Mounting Hardware? | Not Included |
Type | Thermal |
Duty Rating | Severe |
Style | Severe Duty |
Drawing Type | D |
Description | Fan Clutches |
Electronic Clutch? | Non Electronic |
Mount Dia. IN | 3.22 |
Pilot Depth MM | 16.5 |
Overall Dia. MM | 188 |
Bolt Thread | M8 x 1.25 Hole |
Mount Hole Qty | 6 |
Overall Height MM | 103.6 |
Fan Mount Dia. MM | 126.9 |
Mount Dia. MM | 82 |
Fan Bolt Circle MM | 152.4 |
Fan Mount Height MM | 44.7 |
Pilot Dia. IN | 0.75 |
Warranty | 1 year/12,000 miles |
Dia. IN | 7.4 |
Pilot Depth IN | 0.66 |
Overall Dia. IN | 7.4 |
Fan Bolt Circle IN | 6 |
Overall Height IN | 4.08 |
Part Terminology | Engine Cooling Fan Clutch |
