| Mounting Type | Case Mount |
| Distance From Clutch To Mounting Flange | 1.2 |
| Clutch Maximum Diameter | 5.000 |
| Clutch Pulley Diameter | 5.000 |
| Coil Clock Position | 9 |
| Compressor Type | R4 Heavy |
| Pulley Belt Type | V-belt |
| Compatible Refrigerant Oil Type | PAG 150 |
| Pulley Lip Diameter | 5.000 |
| Pulley Ridge Diameter | 5.000 |
| Switch Included | High Pressure |
| Switch Type | Pressure Switch |
| Clutch Included | Included |
| Oil Filled | Included |
| Coil Voltage | 12 |
| Belt Type | V-belt |
| Pulley Groove Quantity | 1 |
| Refrigerant Type | R134A |
| Connector Shape | Spade |
| Terminal Type | Spade |
| Distance Between Mounting Holes | 1.2 |
| Printed Foot Note | Due to new enhancements, compressor may differ in appearance from OE Please refer to installation kit provided w/ each compressor. |
| Pack in Qty of | 1 |
| Style | Piston |
| O-Ring B Quantity | 1 |
| O-Ring A Quantity | 1 |
| New or Reman | New |
| Ctch Dia. MM Prmy | 127.000 |
| Type | GM |
| Switch / Sensor Desc | High Pressure |
| Oil Type | PAG 150 |
| Connector Type | Spade |
| Description | Compressors - New |
| Reman w/o Clutch | [57019] |
| Pulley Diameter MM | 127 |
| O-Ring C Quantity | 2 |
| O-Ring D Quantity | 1 |
| Mounting Hardware? | Not Included |
| Model | R4 Heavy |
| Suction Port Type | O-Ring / Sealing Washer |
| O-Ring C Number/Desc | [24356] / Red Sealing Washer |
| O-Ring B Number/Desc | [24360] / Long Sealing Washer Pilot |
| O-Ring D Number/Desc | [24357] / Green Sealing Washer |
| O-Ring A Number/Desc | [24359] / Short Sealing Washer Pilot |
| Suc Prt Typ Note | Block |
| Electronic Control Valve | No |
| Pulley Diameter IN | 5.000 |
| Groove | 1 |
| California Proposition 65 | WARNING: This product contains a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. |
| Part Note | Due to new enhancements, compressor may differ in appearance from OE Please refer to installation kit provided w/ each compressor. |
| Part Terminology | A/C Compressor |
