U & CV Joints & Drive Shaft

CV Axle Shaft
Part # GM-8240 | Line Code: SRK
brandNameImage
brandNameImage

$106.99
error
Not Fitted

Product Details
expand_less
Outboard Joint Type Conventional
Inboard Joint Type Male
Overall Compressed Length (mm) 638
Overall Compressed Length (in) 25.12
Number of Bolt Holes 0
Number of Outboard Splines 33
Number Of Outboard Joint Bolt Holes 0
Axle Nut Hex Size (mm) 36
Number Of Inboard Splines 28
Axle Nut Thread Size M24X2
Axle Bolt Thread Size N/A
Axle Bolt Length (mm) N/A
ABS Ring Type N/A
Axle Bolt Hex Size (mm) N/A
Axle Nut Socket Size 36
Axle Nut Hex Size (in) 1.43
ABS Ring Tooth Count 0
Axle Nut Locking Type Self-Lock
Number Of Inboard Shaft Bolts 0
New Or Remanufactured New
Inboard Bolt Head Size (in) N/A
Axle Nut Head Type Hex
Outboard Bolt Head Size (in) N/A
Outboard Joint Bolt Thread Size N/A
Inboard Bolt Length (in) N/A
ABS Tone Ring Included No
Outboard Bolt Head Size (mm) N/A
Outboard Bolt Length (in) N/A
Inboard Bolt Head Type N/A
Inboard Bolt Thread Size N/A
Inboard Bolt Head Size (mm) N/A
Inboard Shaft Connection Style Male
Inboard Bolt Length (mm) N/A
Outboard Shaft Connection Style Conventional
Outboard Bolt Head Type N/A
Outboard Bolt Length (mm) N/A
Axle Nut Height (mm) 22
Axle Nut Included Yes
Grade Type Premium
Boot Material CR
Number Of Outboard Shaft Bolts 0
Number Of Inboard Joint Bolt Holes 0
Axle Nut Height (in) .86
Axle Nut Length (in) 1.625
Outboard Joint Boot Material Neoprene
Inboard Joint Boot Material Neoprene
Axle Nut Length (mm) 42
Part Terminology CV Axle Shaft

Features & Benefits
expand_more
Limited Lifetime Warranty. ABS axles fit non-ABS applications unless otherwise noted. ISO 9001:2008 and TS 16949:2009 Certified Company

Application Summary
expand_more

Hummer
