| Thread Size | M10 - 1.0 |
| Grade Type | Standard Replacement |
| Resistor Type | Yes |
| Gap Size | 0.7 |
| Electrical Terminal Type | Non-removable Nut |
| Hex Size | 5/8" (16mm) |
| Washer Included | Yes |
| Ground Electrode Quantity | 1 |
| Insulator Material | Ceramic |
| Manufacturer Heat Range | 7 |
| Ground Electrode Tip Design | Standard |
| Reach | 12.7 |
| Ground Electrode Core Material | Nickel Core |
| Center Electrode Core Material | Copper Core |
| Center Electrode Tip Material | Nickel |
| Seat Type | Gasket |
| Thread Diameter | 0.394 |
| Resistance | 10000.00 |
| Ground Configuration | J-Gap |
| Skirt Length | 0.0 |
| Insulator Height | 36.5 |
| Material Grade | Nickel/Copper |
| Metallurgy | Copper |
| Stock Number | 3066 |
| Part Number | CMR7H |
| Heavy Duty Supplier | Yes |
| Alliance Keywords | spark plug, bougie d'allumage, bougie |
| Short Style Spark Plug | Yes |
| Service Number | CMR7H |
| Part Terminology | Spark Plug |
